This connector supports infrared wireless transmit- ting and receiving device. User must purchase another RS232 cable with a 9-pin D-sub connector at one end to connect with the external RS232 device and another end with 10-pin female connector to con- nect with COM2 connector in the motherboard. This motherboard supports one serial RS232 COM port for legacy compatibility. This motherboard includes a standard floppy disk drive (FDD) connector, supporting 360KB, 720KB, 1.2MB, 1.44MB, and 2.88MB FDDs. By connecting through USB cables with them, user can quickly expand another four USB ports on the front panel. In addition to the four USB ports on the rear panel, this product also provides two 10-pin USB header on its motherboard. By connecting through USB cables with them, user can quickly expand another two USB ports on the front panel. In addition to the six USB ports on the rear panel, this product also provides one 10-pin USB header on its motherboard. If eventually the chassis is closed, the system will send a message out. The system can detect the chassis intrusion through the function of this connector. The connector can be connected to a security switch on the chassis. These fans can be automatically turned off after the system enters S3, S4 and S5 sleeping states. The fan speed can be controlled and moni- tored in “PC Health Status” section of the BIOS Setup. There are three main fan headers on this mother- board.
For a network connection, the RJ-45 connector and three audio outputs are. Fan Connectors : CPU_fAN, SYS_fAN, Nb_fAN Like many motherboards, Foxconn N15235 in characteristics have its own unique.
